當蓋板掩蓋時，線槽接口應與插槽蓋接口移位，避免兩個接口堆疊，從而能夠提高整個線槽的剛性。

When the cover plate is concealed, the slot interface should be shifted from the slot cover interface to avoid stacking two interfaces, thereby improving the rigidity of the entire slot.

銜接銜接頭時的施工辦法。內部（外部）銜接頭附件是在相同規格線之間運用封閉。當結構能夠采用約15-20厘米的相同尺寸的截面，而不是銜接頭部成品?！般暯悠鳌币话闱度刖€槽（內銜接器）的內部，以堅持整個線路槽的外觀。將“關節”鉆頭更好，用自攻螺釘或芯鋁釘固定“銜接器”。

Construction methods for connecting joints. Internal (external) connector attachments are enclosed between lines of the same specification. When the structure can adopt a cross-section of about 15-20 centimeters of the same size, instead of connecting the head finished product. The "connector" is generally embedded inside the cable tray (inner connector) to maintain the appearance of the entire cable tray. Better use a "joint" drill bit and secure the "connector" with self tapping screws or core aluminum nails.

缺少陽角關節時的施工辦法。剛性角接頭用于線槽作為90°曲折的線槽。在制作時，插槽側高度尺寸高度尺寸，在一條線槽的結尾底部，而且用切開切出DIPK。在另一條線槽端，每次切開沿凹槽的底外表和兩個槽的旁邊面的刀，防火電纜橋架廠家切開深度是凹槽側的高尺寸，然后切開曲折槽的底部，然后曲折部分銜接到前部槽口用鉚釘固定。相應的槽蓋曲折，而且能夠發現線槽由90°曲折制成。

The construction method when there is a lack of male corner joints. Rigid corner joints are used for trunking as 90 ° winding trunking. During production, the height dimension of the slot side is at the bottom of the end of a wire slot, and DIPK is cut out by cutting. At the other end of the cable tray, each time a knife is cut along the bottom surface of the groove and the side surfaces of the two grooves, the fireproof cable tray manufacturer cuts to the height of the groove side, then cuts the bottom of the curved groove, and the curved part is connected to the front slot and fixed with rivets. The corresponding slot cover is tortuous, and it can be observed that the wire slot is made of a 90 ° twist.

電纜橋架時的施工辦法。當線槽在90°內曲折時運用曲線角接頭，這能夠經過切開罐自身來到達目的。這種做法如下：防火電纜橋架廠家在線槽的雙面槽側，它在內彎的旁邊面上穿插。運用鐵切成兩個45°的間隙，然后線槽減小到間隙，防火電纜橋架廠家使得凹槽的旁邊面向外，然后鉚接固定固定，以便制作簡單，凹槽相應部分的蓋能夠曲折，而且能夠在蓋子的兩邊切開兩邊，而且能夠制作槽蓋。

Construction methods for cable trays. When the trunking bends within 90 degrees, use curved corner joints, which can be achieved by cutting open the can itself. This approach is as follows: The fire-resistant cable tray manufacturer inserts the double-sided groove side of the cable tray on the side of the inner bend. Cut the iron into two 45 degree gaps, then reduce the cable tray to the gap. The fire-resistant cable tray manufacturer makes the side of the groove face outward, and then rivet and fix it for easy production. The cover of the corresponding part of the groove can be bent, and both sides of the cover can be cut open, and the groove cover can be made.
